3-Way Multi-Port Sanitary Stainless Steel Ball Valve

$925.71 USD

Sale Sold out

Shipping calculated at checkout.

Size 1 Inch 1 1/2 Inch 2 Inch 3 Inch

Product variants

Quantity

Need custom lengths, sizes or fittings?

Whether you are looking for a custom sanitary transfer solution, need an 3A or FDA approved component part, or just searching for quantity pricing, submit a request for a custom quote today.

The 3-Way Multi-Port Sanitary Stainless Steel Ball Valve is a specialty sanitary item used in the wineries, breweries, and distilleries market as well as in the larger food and beverage processing markets. 50% stainless steel reinforced PTFE seat is specified for higher temperature pressure applications in a sanitary process. Food grade material

Construction

CF8M stainless body, ends and ball
50% stainless steel reinforced PTFE seat is specified for higher temperature pressure applications in a sanitary process. Food grade material
ISO 5211 mounting pad

Features

Full port design
Blow-out proof stem
Live-loaded stem packing
Lock-out, tag out

Attributes

Material | Stainless Steel
Seat | 50% Stainless Steel Reinforced PTFE
Port | T Port

Multi-Port Sanitary Stainless Steel Ball Valve Repair Kits Available
